1)Electrical:
1.1 Contact Resistance: 30M? Max
1.2 Insulation Resistance:1000M? Min
1.3 Withstanding VOltage :500V DC
1.4 Current rating 1.0AMP Max
1.5 TOtal Mating Force :4.5kg Max
1.6 TOtal Unmating Force :0.7kg Min
1.7 Temperature Rage :-25%%D+80%%D
2)Material:
2.1 Housing: LCP BLACK UL
94V-0
2.2 Shell :C2680 T=0.30
2.3 Contact :C5191 T=0.25
3)Finishing:
3.1 PLating: Au or Sn Over 100U Ni
3.2 Crimp Terminal :Gold -plated contact points Tin -lead foot
3.3 Shekk:Nickel-plting塑胶材料：PBT，LCP，PA6T，PA9T
|
|
